GIADA DN73 RK3328 ANDROID 7.1 16GB 2GB

home_software_subheader_sep
DN73-N2-3328R31E4








Giada DN73 RK3328

Android 7.1 16GB 2GB

The Giada DN73 is an entry-level embedded computer and is ideal for signage player applications in hospitality, retail, commercial, service and advertising roles.

  • RK3328 QUAD-CORE CORTEX-A53 UP TO 1.5GHZ

  • ONBOARD DDR4 2GB MEMORY

  • 1 X HDMI, SUPPORTING 4K 60HZ DISPLAY

  • ONBOARD EMMC 16GB

DN73-N2-3328R31E4




Compact and fanless design

Brings organizations all the performance and efficiency of the RK3328 Quad-Core Cortex-A53 CPU, plus an HDMI output with up to 4K resolution support.








Versatile for a more mobile experience

Its HDMI, USB ports, OTG support, gigabit LAN, Android OS, and support for mini-PCIe 4G cards make it very versatile for a more mobile experience. It can also be mounted in various ways thanks to its VESA mount support and can easily be hidden behind a monitor or large format display.
DN73-N2-3328R31E4

Specification

Processor:
  • CPU: RK3328 Quad-core Cortex-A53
  • Frequency: Up to 1.5GHz
  • Chipset: SOC
Memory:
  • Type: DDR4
  • Socket: Onboard
  • Max Size: 2GB (Optional: 1GB)
Graphics:
  • GPU: Mali-450MP2 GPU
  • Graphic Engine: 4K H.264 30FPS/H.265 video decoder, 2160P video encoder/1080P 60fps video decoders
  • HDMI: 1 x HDMI (Max. 4K @60Hz)
Network:
  • Controller: Realtek RTL8211E Gigabit Ethernet
  • Interface: 1 x RJ45
I/O:
  • USB: 1 x USB 3.0, 2 x USB 2.0, 1 x USB2.0 OTG
  • Display Interface: 1 x HDMI
  • LAN: 1 x RJ45
  • Serial Port: 1 x RS232
  • Audio: 1 x MIC-IN, 1 x AUDIO-OUT
  • Mini-PCIe: 1 x Full-size Mini-PCIe for 3G/4G
  • SIM: 1 x SIM Slot
  • WiFi+BT on Board: 1 x WiFi Module Onboard (2.4G, IEEE802.11 a/b/g/n) Optional: WIFI 5G
  • LED Indicators: 1 x HDD LED, 1 x Power LED
Storage: eMMC: Onboard eMMC 16GB (Optional: 8GB /32GB/ 64GB)
JAHC Tech:
  • WatchDog Timer: 0~255 Second Time Out Support
  • Auto Power On: Power Activated Automatically Start
  • Remote Control: By IR Controller for Power On
  • RTC: Set Up Independently Every day, A Week as a Cycle
Operation System: Android: Android7.1 / Android 10.0
Power:
  • Power Type: DC-IN
  • Input Voltage: 12V/2A
Environment:
  • Operating Temperature: 0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow
  • Relative Humidity: 95%@40℃ (non-condensing)
Certification: CE, FCC Class B
Mounting: Desk/Wall Mounting and VESA Mounting Kit (JT-NUC-JC530)
Construction: Metal
Fanless: Yes
Colour: Black
Dimensions: 11.6 x 10.7 x 3 cm

WHAT’S IN THE BOX:
  • Giada DN73 RK3328 Quad-Core Entry Level Signage Player – Black x1
  • Power Cable x1
  • User Manual x1
